4 SPECIFICATION
4.1
SPECIFICATION
TECHNICAL DESCRIPTION
The mower is a self-propelled machine with four-wheel drive, controlled by a transmitter (remote radio controller)
signal. Its unique wheel-steering technology ensures a high maneuverability both on level ground and on slopes.
The basic part of the machine is formed by a square solid frame, which is connected to a sliding frame. The middle
part of the sliding frame carries all transmission parts such as the engine, the hydraulic pump, the hydraulic motor
and the control unit. 4 mowing blades are attached to the bottom part of the frame. An electromagnetic clutch is
placed between the main belt pulley and the engine. Circles formed by the rotation of blades do not overlap. The
blades are fixed and attached to the flanges by bolt. The cutting deck is open on two sides in order to facilitate
the intake and discharge of grass. These openings are covered by a chain curtain and by a rubber cover, which
prevent the throwing of undesirable objects. A steel bumper above the rubber cover on the outside of the mower
marks the safe distance from the blades. Transmission is by chains and gears on all four wheels. The wheels are
driven by two hydraulic motors through V-belts. Wheels are steered by an electric motor. The gel battery and the
control unit are situated in the front part of the mower. The mower is controlled by a multi-channel transmitter.
TECHNICAL SPECIFICATION
4.2
NOISE EMISSIONS
The mower emits the following noise: Sound pressure level L
WA =
99,9 dB
Guaranteed Sound pressure level L
WA
= 101,0 dB
The measuring was carried out in conformity with ISO 3744
Noise at the operator’s station (ear): L = 81. dB (A) Leq - Measured in the distance of 3 m from the machine
according to EN 11 201
