10.6
ENGAGING THE BLADES
The mowing blades can only be engaged when
the engine is running.
Set the maximum mowing height with controller
(7).
First increase the engine speed by regulator (14),
then push the button for blades engagement (5)
– the mowing device turns on. The beacon flashes
red. Set the working position of the blade by the
height of cut controller (7) on the RC.
Do not engage the mowing blades
in tall grass, damage to the clutch
may result.
If you wish to mow tall grass, move
the mower to a place without tall grass and
then turn the blades on. When engaging the
blades stand in a safe distance from the
mower. Do not engage the blades if there are
people near the mower. The rotating blades
may throw objects.
10.7
DISENGAGING THE BLADES
To disengage blades, press button (6). If you are
not planning to continue mowing, set the
maximum height of cut with controller (7).
10.8
HEIGHT OF CUT ADJUSTMENT
The machine has a variable mowing height. As a
standard the height of cut can be adjusted from
90 to 140 mm / 3.5 to 5.5 inch (70-120 mm).
The mowing height can be adjusted by switch (7)
on the RC. Follow the marks on the body of the
mower.
If the grass growth is high or wet, select a higher
mowing position
The lowest position is used when mowing well-
maintained and even areas.
When mowing unknown areas
for
the first time, we recommend to
mow with blades in a higher
position and - after finishing
mowing - to re-examine the area for
undesirable objects. The next cut should
only be done after the grass cuttings have
dried up.
Set an approximate height of cut, mow a few
meters of the area and check that the height of the
cut grass meets your expectations
The height of cut on a slope may
significantly vary from that on a
level surface.
Switch 7 has 3 positions: The
maximum and minimum limit
position and the third intermediate
position, which preserves the current
height set-up.
Cleaning the mowing mechanism
After each use the mowing mechanism must be
carefully cleaned, especially the inner walls of the
mowing deck. The cleaning should be carried out
with a scraper. The mower must not be washed by
power washer or other high-pressure devices.
When cleaning, secure the machine against
moving.
Raise the mowing mechanism to the transporting
position. When cleaning, also check the blades.
Proper maintenance and treatment of the mowing
mechanism increases the quality of work and
durability of your machine.
After cleaning and drying, especially if the mower
will not be used for a longer time, treat all scratched
parts with preservative coating
If you are lifting the mower into the
service position during cleaning,
make sure that you secure it against
movement and fall. Disconnect the
battery, remove the spark plug
terminal and press the EMERGENCY
STOP button on the mower.
IT IS PREFERABLE TO DO
MAINTENANCE WHEN THE ENGINE IS
COLD.
THE MOWER MUST NOT REMAIN IN
THE SERVICE POSITION FOR MORE
THAN 2 HOURS. Exceeding this time
can lead to unrecoverable damage to
the machine.
10.9
ENGAGING THE WINCH
To work with stabilize winch switch button (15) into
ON position.
For instruction how to use stabilizing winch please
refer to “Winch Operation Manual”.
