To Next PageTo Next PageWhy my SPIDER ILD02 EFI Lawn Mower leaves unmown grass behind, only one blade is turning?
If your SPIDER Lawn Mower leaves unmown grass behind and only one blade is turning, it is likely due to a broken V-belt XPB 2410, which will need to be replaced.
Why does my SPIDER Lawn Mower engine smoke so much?
If your SPIDER Lawn Mower engine smokes excessively, it could be due to a few reasons. The air filter might be heavily polluted, requiring cleaning or replacement. Alternatively, there might be too much oil in the engine; check the oil level and remove any excess. Finally, the issue could stem from bad quality or the wrong type of fuel, in which case you should replace it with natural 95 fuel.
What to do if SPIDER ILD02 EFI engine doesn't have enough power?
If your SPIDER Lawn Mower engine doesn't have enough power, consider these possible causes: a polluted air filter (clean or replace it), bad fuel (replace it with natural 95), a loosened rocker arm or detached lifting rod valves (reassemble and reset valve clearances), a bad spark plug (clean or replace it), or a broken ignition coil (replace it).
Why does my SPIDER ILD02 EFI motor run irregularly?
If the SPIDER Lawn Mower motor runs irregularly, it could be due to several reasons: bad spark plugs (clean or exchange them), broken ignition coils (exchange them), water in the fuel system (clean the fuel system thoroughly), blocked fuel hoses (clean them), a polluted fuel system (clean it), or the engine has infiltrated/false air (reseal the joints, fuel system/inlets/cylinder).
What to do if my SPIDER ILD02 EFI Lawn Mower does not turn?
If your SPIDER Lawn Mower is not turning, start by checking the power cable to ensure it's properly engaged. Then, inspect the turning servomotor for any issues. A bad contact between the carbon and the commutator may be the problem; in this case, clean the commutator and check the carbon blocks. Other potential causes include an exhausted battery (check/recharge it, and check fuses and cable connections), a broken steering servomotor (replace it), a control unit fault (replace it), or a broken joystick in the remote control (replace it).
Why SPIDER ILD02 EFI doesn't have power when driving on slopes?
If your SPIDER Lawn Mower machine doesn't have power when driving on slopes, it could be due to a few reasons. First, check the hydraulic oil level in the oil tank and replenish if necessary. Second, worn mechanical parts of the hydraulic system can cause this issue, requiring you to exchange the worn parts. Additionally, a loosened bypass bolt on the hydraulic pump should be tightened. Lastly, a broken drive servomotor will need to be exchanged.
Why do the fuses blow out often on my SPIDER ILD02 EFI?
If the fuses in your SPIDER Lawn Mower blow out often, it could be due to a battery in bad shape, often caused by turning the wheels while standing, which overloads the alternator. Test the state of the battery and replace it if it's bad, and remember to steer while moving. Another cause could be extreme power consumption due to burned-out coils in the turning servomotor or under-inflated tires. Replace the drive servomotor if needed, and check the tire pressure as prescribed.
Why doesn't the elevation regulation stop when at max or min height on my SPIDER Lawn Mower?
If your SPIDER Lawn Mower experiences the elevation regulation not stopping at max or min height, it indicates that one of the height sensors is broken and needs to be replaced.
Why does my SPIDER ILD02 EFI Lawn Mower accelerate and decelerate on its own?
If your SPIDER Lawn Mower accelerates and decelerates on its own, it could be due to a broken drive servomotor (replace it) or a broken control unit (replace the unit).
Why SPIDER ILD02 EFI turns off while working?
If your SPIDER Lawn Mower is turning off while working, it could be due to interference nearby from high voltage or transmitters, which is not a machine fault. Alternatively, bad sparkplugs can interfere with the remote/unit, so replacing them might resolve the issue.
Importance of the manual, machine's intended use, and operator qualifications.
Details intended use, slope limitations, and terrain conditions for mower operation.
Lists forbidden operations to ensure safety and prevent damage to the machine.
Explains how to locate identification labels on the engine and mower for reference.
Provides instructions for proper disposal of machine parts and materials according to regulations.
Outlines essential checks before and during operation to prevent accidents.
Specifies operator and environmental requirements for safe mower use.
Illustrates and explains the meaning of safety symbols (pictograms) used on the machine.
Provides detailed technical specifications of the mower's components and capabilities.
Details the noise levels emitted by the mower according to standards.
Presents the EC/EU declaration of conformity for the remote-controlled mower.
Displays the certificate of stability issued by the testing laboratory.
Illustrates and explains the meaning of safety symbols (pictograms) used on the machine.
Provides guidance on recommended mowing techniques for different terrains and conditions.
Details the layout and function of each button and control on the remote radio controller.
Identifies the main control element on the mower itself, the emergency stop/ignition switch.
Explains the indicators and warnings on the remote controller and mower displays.
Lists safety systems, interlocks, and emergency shutdown procedures for the mower.
Instructions for unpacking, preparing, and inspecting the mower upon delivery.
Explains the function and use of the hydraulic pump by-pass for manual handling.
Details the procedure for checking and maintaining the engine oil level.
Outlines the process for checking and refilling the hydraulic drive oil.
Covers battery preparation, connection, and charging for the mower.
Details the correct and safe procedures for transporting the mower.
Provides a step-by-step guide for starting the mower's engine using the remote control.
Describes normal and emergency engine shutdown procedures.
Explains how to safely engage and disengage the mowing blades.
Covers adjusting mowing height and engaging the stabilizing winch for slopes.
Explains how to control the machine's movement using the joysticks.
Details how to control and select driving speeds for optimal mowing.
Provides crucial safety and operational advice for driving the mower on slopes.
Explains how to safely stop and use skid steering on slopes.
A comprehensive chart detailing regular maintenance tasks for the mower and their frequency.
A chart outlining the maintenance schedule for the engine based on operating hours.
Details workshop maintenance activities for the engine, requiring trained personnel.
Step-by-step instructions for changing the engine oil.
Instructions for cleaning the fuel tank and addressing potential blockages.
Outlines maintenance requirements for the hydraulic drive system.
Details how to check and refill oil in the hydraulic drive.
Explains how to check and tension the V-belts for the hydraulic pump, clutch, and travel wheels.
Provides instructions for adjusting the wheel geometry, recommending professional service.
Details final gear drive chain adjustment and electric circuit maintenance.
Explains the electromagnetic clutch function and adjustment, recommending dealer service.
Instructions for checking and tightening the steering chain.
Details the location and types of fuses in the mower and their functions.
Covers checking, sharpening, balancing, and replacing the mowing blades.
Covers changing wheels, tyre pressure, and height adjustment mechanism care.
Provides guidance on lubrication, cleaning, and torque specifications for the machine.
A chart showing recommended engine oil types based on external temperatures.
Explains technical plate information and lists tools for maintenance and servicing.
Explains the function of the auxiliary drive brake and its manual disengagement.
Covers the regular examination, maintenance, and storage of the mower's battery.
A table listing common engine faults, their probable causes, and solutions.
Details engine power loss, smoke issues, and mowing unit faults with solutions.
Addresses problems with machine power, reaction, driving, and turning capabilities.
Discusses skid steering, elevation control problems, and remote control system faults.
Instructions for preparing the mower for storage at the end of the season.
Outlines the general provisions and terms of the limited warranty for new Spider equipment.
General| Brand | SPIDER |
|---|---|
| Model | ILD02 EFI |
| Category | Lawn Mower |
| Language | English |
