Operation Manual – Spider ILD02 EFI
37 / 55
rev. 01-01-02-2021
For Control Units S/N 96 001 xxxxx there is a possibility of neutral position adjustment by so called
Teach mode allowing trimming of neutral position on Remote controller
1) Activate the
programming mode
Set all proportional channels to zero position.
Release the EMERGENCY STOP switches and wait till the radio connection is
present.
Press and hold the “Motor Start” (4) and “Motor Stop” (3) buttons for 5 seconds.
As a confirmation the horn will be activated briefly (2 times).
Do NOT press the “HORN/ENABLE” (12) button!
2) Adjust the Zero
Position value
Standard value is 0.
Use steering joystick 9 for adjusting the value (left/right).
Each time you push the steering joystick to the left, the value will decrease by one.
Pushing the steering joystick to the right will increase the value by one.
Each time you move the joystick to the left or right, the horn will acknowledge the
movement.
3) Save the value
For saving the value after changing, you have to push the “HORN/ENABLE” (12)
button.
The values are stored now.
4) Chec j the values
Press the EMERGENCY STOP switches !!!ATENTION!!! – press first the
EMERGENCY STOP switch on the remote controller and after the mower´s
EMERGENCY STOP switch (not in opposite order). Wait 2-3 seconds. Release the
EMERGENCY STOP switches again and prepare the mower to operate by pressing
the “HORN/ENABLE” (12) button.
If you are not content and want to change the values again, start over at point 1.
Restore the factory
settings
/ default value
Set all proportional channels to zero position. Release the EMERGENCY STOP
switches. Wait till the radio connection is present. Press
and hold the buttons for “Motor Start” (2) and “Frequency check/change” (13) for 5
seconds.
The factory settings / default values are restored automatically.
As a confirmation the horn will be activated briefly (4 times).
Release the buttons. Press the EMERGENCY STOP switches !!!ATENTION!!! –
press first the EMERGENCY STOP switch on the remote controller and after the
mower´s EMERGENCY STOP switch (not in opposite order). Wait 2 seconds.
Release the EMERGENCY STOP switches again and prepare the mower to operate
by pressing the “HORN/ENABLE” (12) button.
