8 Connecting the station to the car
The first procedure to be performed is connecting the circuit to the ATF station, with which you will be later able to
empty and charge the circuit very easily.
To do so, you need the appropriate adapters.
N.B.: The description here below might not adhere perfectly to the gearbox in object depending on the
gearbox type, please check.
The ways to get connected to the ATF can be the following:
• Original Circuit Schema on the vehicle
• Schema 1 – Connection of the ATF station
• Schema 2 – Connection of the ATF station (without washing the radiator)
In some gearbox types it is possible to create an alternative connection as shown here below.
CAUTION: In this case there is no need to wash the radiator.
