10.5 Cable / wire and connector data
Mains and signal connector
Termination
Rising clamp plug-in terminal blocks with screw
connectors
Cable size 0.02 mm² (24 AWG) to 2.5 mm² (12 AWG).
Stripping length 5 – 6 mm
Note: Use only the connectors supplied by Spirax Sarco Ltd – Safety and Approvals may
be compromised otherwise.
TDS probe
Type High temperature
Shield type Screened
Number of cores
4 (CP32), 4 (CP10 and CP20 - For most applications
the 1.25 m (4 ft) heat resistant cable will need to be
extended using a junction box) or 2 (CP10 and CP30)
Gauge 1 – 1.5 mm² (18 - 16 AWG)
Maximum length
100 m (9990 and 999.0 ranges)
30 m (99.90 range)
10 m (9.990 range)
Recommended type
Prysmian (Pirelli) FP200,
Delta Crompton Firetuf OHLS
Pt100 probe
Type High temperature, twisted
Shield type Screened
Number of cores 3
Gauge 1 – 1.5 mm² (18 - 16 AWG)
Maximum length 100 m (328 ft)
Recommended type various
0 / 4 - 20 mA output
Type Twisted pair
Shield type Screened
Number of pairs 1
Gauge 0.23 - 1 mm² (24 - 18 AWG)
Maximum length 100 m (328 ft)
Recommended type various
RS485 communication
Type EIA RS485 twisted pair
Shield type Screened
Number of pairs 2 or 3
Gauge 0.23 mm² (24 AWG)
Maximum length 1 200 m (4000 ft)
Recommended type Alpha Wire 6413 or 6414
LAN Cat 5 or Cat 5E ScTP (screened), FTP (foil) or STP (shielded) cable can be used,
but limited to 600 m.
