37
6.2 Commissioning mode navigation
After the correct pass code has been entered the display shows:
To exit the commissioning mode at any stage, press and hold the
button to return to the run mode.
Pressing the and buttons scrolls through the various first
level menus.
Pressing the button enters a particular sub-menu. The first
menu title will remain displayed at the top of the screen and the
new sub-menu will appear on the next line. As you progress through
the menu, the longer the list becomes. This aids navigation of the
menu structure.
MODE
INPUT
T COMP
( °C)
200
6.2.1 Changing parameters
If a particular sub-menu requires a parameter to be modified, the
corresponding units (if any) will appear on the next line (in brackets)
and the parameter itself will appear on the bottom right hand corner.
The first digit will start flashing and the parameter can be modified
as described in the previous section (See the adjacent example).
