3.7 MVT10 Dimensions/weights (approximate) in mm and kg
The ILVA20/MVT10 can be supplied with either
1 m or 2 m long impulse hoses, with " NPT
screwed ends.
It can also be supplied without hoses, where the
intention is to hard pipe the assembly (hard pipe
supplied by others).
Impulse hoses
Weight
" NPT 1 m 0.5 (pair)
" NPT 2 m 1 (pair)
A
B
C
MVT10 mass flow transmitter, manifold and
impulse hoses and fixing clamp
A B C Weight
209 264 220 8
'U' bolts to suit DN50 pipe
