IM-P402-93 AB Issue 7
15
20
19
18
17
16
9
8
7
2
1
6.7 Wiring - modulating control
(electric actuator with feedback potentiometer)
(All relays shown in the power off position)
Note: It is essential to select the correct sensitivity on the PA20 preamplifier,
(see Installation and Maintenance Instructions for details).
Note:
Terminals
1, 3, 5 and 7
are common
Select
voltage
internally
Capacitance probe
L
N
1
2
4
EL5600 actuator
Fill / empty control
Terminal block X 5
1 000 ohm auxiliary feedback potentiometer
Fill / empty control
15
14
16
Terminal block X 4
Fig. 14
Fuse 3 A max.
Input
Level input
+
