Spirax Sarco LC2610 - Modulating Control

IM-P402-93 AB Issue 7
5
3.2 Modulating control:
-
Modulating valve control using valve motor drive or 4 - 20 mA control signals.
- Two alarm outputs.
- 4 - 20 mA level output.
Note: The 4 - 20 mA level output is only available when the LC2610 is configured for valve motor
drive systems.
Fig. 3
