IM-P402-93 AB Issue 7
37
11. Settings table
This Table shows all changeable options, and enables you to record the security code and
settings you have chosen. It provides a convenient reference should future changes be required.
Changeable options Default settings Your Changes
(as supplied) settings
CODE (security code) 00
CONTROL TYPE-
Proportional Proportional
On / off
PUMP ACTION-
In (e.g. boiler level control) In
Out (e.g. condensate tank)
INPUT LEVEL-
0 - 6 V (Level probe) 0-6 V
4 - 20 mA (Transmitter)
LVLINPUT O/RNGDET
(level input out of range detect)
No
SET POINT 50 %
CONTROL BAND 50 %
ALARM LOW 00 %
ALARM HIGH 99 %
ALARM DELAY 00 s
ALARM LOCKOUT No
VALVE DRIVE-
Relay Relay
4 - 20 mA
WATER METER No
STEAM METER No
