Appendix A: Landslide Test Server NIC Configurations
Supported NIC Configurations and Port Names
Spirent Landslide Test System Installation Guide | 57
Table A-9. One dual-port, 25 GbE or 40 GbE NIC and one, two or three quad-port 1 GbE
NICs, 2x 25/40 GbE ports and 4x, 8x or 12x 1 GbE ports
Slot Card Ports
0 Unused NA
1 Dual-port 25/40 GbE NIC (L-NIC-73/-74) eth2, eth3
2 First quad-port, 1 Gbps eth4, eth5, eth6, eth7
3 Third quad-port, 1 Gbps eth12, eth13, eth14, eth15
4 Second quad-port, 1 Gbps eth8, eth9, eth10, eth11
5 Optional L-ACC-007 or L-ACC-008 IPSec
Accelerator
NA
6 Unused NA
Table A-10. Two dual-port 25 GbE or 40 GbE NICs and one or two quad-port 1 Gbps, 4x 25/
40 GbE ports and 4x or 8x 1 GbE ports
Slot Card Ports
0 Unused NA
1 First dual-port 25/40 GbE NIC (L-NIC-
73/-74)
eth2, eth3
2 First quad-port, 1 Gbps eth4, eth5, eth6, eth7
3 Second quad-port, 1 Gbps eth10, eth11, eth12, eth13
4 Second dual-port 25/40 GbE NIC (L-
NIC-73/-74)
eth8, eth9
5 Optional L-ACC-007 or L-ACC-008
IPSec Accelerator
NA
6 Unused NA
