Appendix A: Landslide Test Server NIC Configurations
Supported NIC Configurations and Port Names
58 | Spirent Landslide Test System Installation Guide
C100-M2 Test Server with Supported L-NIC-66 Configurations
Table A- 11 and Table A-12 describe L-NIC-66 configurations that are supported on the
C100-M2 test server.
Table A-11. One quad-port, 10 Gbps NIC and one, two, or three quad-port 1 Gbps NICs, 4x
10 Gbps ports and 4x, 8x or 12x 1 Gbps ports
Slot Card Ports
1 Second quad-port, 1 Gbps eth10, eth11, eth12, eth13
2 Quad-port 10 Gbps (L-NIC-66) eth2, eth3, eth4, eth5
3 First quad-port, 1 Gbps eth6, eth7, eth8, eth9
4 Third quad-port, 1 Gbps eth14, eth15, eth16, eth17
5 Optional L-ACC-006 IPSec
Accelerator
NA
6 Unused NA
Table A-12. Two quad-port 10 Gbps NICs and one or two quad-port 1 Gbps NICs, 8x 10
Gbps ports and 4x or 8x 1 Gbps ports
Slot Card Ports
1 First quad-port, 1 Gbps eth10, eth11, eth12, eth13
2 First quad-port 10 Gbps (L-NIC-66) eth2, eth3, eth4, eth5
3 Second quad-port 10 Gbps (L-NIC-66) eth6, eth7, eth8, eth9
4 Second quad-port, 1 Gbps eth14, eth15, eth16, eth17
5 Optional L-ACC-006 IPSec
Accelerator
NA
6 Unused NA
