Appendix A: Landslide Test Server NIC Configurations
Supported NIC Configurations and Port Names
Spirent Landslide Test System Installation Guide | 59
C100-M2 and Earlier Test Server Supported NIC Configurations
The following tables describe the NIC configurations that are supported on the C100-M2
and earlier test servers.
Notes: • Slot 6 is unused.
• L-ACC-006 Legacy IPSec accelerator card is optional for all configurations.
Table A-13. One, two, three or four quad-port 1 Gbps NICs, 4x, 8x, 12x, or 16x 1 Gbps
ports (L-ACC-006 IPSec Accelerator Card optional)
Slot Card Ports
1 Third quad-port, 1 Gbps eth10, eth11, eth12, eth13
2 First quad-port, 1 Gbps eth2, eth3, eth4, eth5
3 Second quad-port, 1 Gbps eth6, eth7, eth8, eth9
4 Fourth quad-port, 1 Gbps eth14, eth15, eth16, eth17
5 Optional L-ACC-006 IPSec
Accelerator
NA
Table A-14. One dual-port 10 Gbps NIC and one, two or three quad-port 1 Gbps NICs, 2x
10 Gbps ports and 4x, 8x or 12x 1 Gbps ports (L-ACC-006 IPSec Accelerator
Card optional)
Slot Card Ports
1 Second quad-port, 1 Gbps eth8, eth9, eth10, eth11
2 Dual-port, 10 Gbps (AONIC) eth2, eth3
3 First quad-port, 1 Gbps eth4, eth5, eth6, eth7
4 Third quad-port, 1 Gbps eth12, eth13, eth14, eth15
5 Optional L-ACC-006 IPSec
Accelerator
NA
