Spypoint mini-LIVE - Components

5
Photo lens
Invisibles LEDs
Test light
Light sensor
Battery case
Fresnel lens
1
2
3
4
5
6
7
8
Mounting bracket
Slot for installation strap
Tripod mount
9
1
2
3
6
4
5
7
8
9
1210 1411 13 15
16 17 18
19
Cable lock hole
BUSY LED
Viewing screen
Navigation buttons
Microphone
(mini-LIVE-4G, mini-LIVE-4GV,
mini-LIVE-CV)
Power button
10
11
12
13
14
15
12V/Solar panel jack
USB port
SD card slot
SIM card slot
(mini-LIVE, mini-LIVE-4G)
Built-in speaker
(mini-LIVE-4G, mini-LIVE-4GV
,
mini-LIVE-CV)9
16
17
18
20
20
Components
