SRAM G2 RE User Manual

12
Caliper Piston Removal
Remove the caliper body bolts.Remove the caliper body bolts.
Separate the caliper halves and remove the banjo. Separate the caliper halves and remove the banjo.
Set the banjo aside.Set the banjo aside.
Remove the banjo o-rings and discard them.Remove the banjo o-rings and discard them.
2
5 mm
5 mm
3
Pick Pick

SRAM G2 RE Specifications

General

Brand	SRAM
Model	G2 RE
Category	Bicycle Accessories
Language	English
