SRAM G2 RE User Manual

34
Reservoir Cap Installation
Reservoir Cap Installation
Insert and seat the bladder into the reservoir cap. The bladder should Insert and seat the bladder into the reservoir cap. The bladder should
be flush with the cap with each hole centered and seated over the bolt be flush with the cap with each hole centered and seated over the bolt
holes in the cap.holes in the cap.
Insert the reservoir cap/bladder assembly onto the lever body.Insert the reservoir cap/bladder assembly onto the lever body.
Use a torque wrench and a T10 TORX bit socket to tighten each Use a torque wrench and a T10 TORX bit socket to tighten each
reservoir cap bolt to 1.2 N·m (10.5 in-lb).reservoir cap bolt to 1.2 N·m (10.5 in-lb).
1
2
3
T10 T10
T10 1.2 N·m (10.5 in-lb) T10 1.2 N·m (10.5 in-lb)
