Lever Blade Removal
Lever Blade Removal
Place the lever pivot on top of a 6 mm socket. Tap a 4 mm hex wrench Place the lever pivot on top of a 6 mm socket. Tap a 4 mm hex wrench
with a hammer to remove the pivot pin. with a hammer to remove the pivot pin.
Remove the lever blade assembly.Remove the lever blade assembly.
The lever blade assembly will separate into four pieces when removed The lever blade assembly will separate into four pieces when removed
from the lever body: SwingLink cam, lever bias spring, main pivot from the lever body: SwingLink cam, lever bias spring, main pivot
bushing, and lever blade assembly.bushing, and lever blade assembly.
Remove the lever pivot bushings. Remove the lever pivot bushings.
Clean the bushings and set them aside.Clean the bushings and set them aside.
1
4 mm 6 mm socket
2
3
