SRAM G2 RE User Manual

32
Lever Blade Installation
Lever Blade Installation
Hold the spring and main pivot clip in place while installing the lever Hold the spring and main pivot clip in place while installing the lever
blade. blade.
Insert the Reach Adjust Screw pin into the cam hole.Insert the Reach Adjust Screw pin into the cam hole.
Insert the pushrod into the piston.Insert the pushrod into the piston.
1
2
