22
2x
1
2
T30
12 N·m
(106 in-lb)
Road SRAM AXS 4-Bolt
Chainring Installation
Montering af SRAM AXS-klinge
med 4 bolte til
Montarea foii pedaliere pentru
osea SRAM AXS cu 4 uruburi
Montaż szosowej zębatki
przedniej Road SRAM AXS na 4
śruby
Montáž silničního převodníku
SRAM AXS se 4 šrouby
Τοποθέτηση δακτυλίου αλυσίδα
4 πουλονιών SRAM AXS για
ποδήλατα δρόου
󻗋󻉋󻩫󽀧󾖴󼨣󼓧󻜰󾖴󻺓󼯇
Install the chainrings so the derailment pin
on the large chainring and the point on the
small chainring is in line with the crankarm.
Thread the bolts into the chainrings and
tighten.
Montér klingerne således, at
afsporingsstiften på den store klinge og
punktet på den lille klinge flugter med
pedalarmen. Før boltene ind i klingen og
stram til.
Montai foile pedaliere astfel încât tiftul
de comutare de pe foaia cea mare i
punctul de pe foaia cea mică să fie
pe aceeai linie cu braul pedalier.
Înurubai uruburile în foile pedaliere i
strângei-le.
Zainstaluj zębatki tak, aby kołek ustalający
na dużej zębatce i punkt na małej zębatce
były ustawione w jednej linii z ramieniem
korby. Wkręć śruby w zębatki i dokręć je.
Natočte převodníky při montáži tak, aby byl
kolík velkého převodníku a bodová značka
na malém převodníku v rovině s klikou.
Našroubujte šrouby převodníků a utáhněte
je.
   
     
   
   
     
   
    
   
󼷟󾖴󼨣󼓧󻜰󼌿󾖴󼓷󻀃󾖴󼓣󼸷󾖴󻦘󼜯󾖴󽊯󺩫󾖴󼔀󼒯󾖴󼨣󼓧󻜰󼌿
󼓷󻀃󾖴󼕿󼓣󾖴󼷛󻔜󼷛󼋃󺩫󾖴󼓫󼜰󻺏󼓣󾖴󻆇󻄳󻗌
󼨣󼓧󻜰󼒳󾖴󻺓󼯇󽋘󻀷󻁓󼨣󼓧󻜰󼌿󾖴󻩫󽀧󻛫󾖴󺷫󼐟󺩏
󼗟󼓴󻀷󻁓
Install
Monter Montare
Montuj Namontovat
Τοποθέτηση
󻺓󼯇
Torque
Spænd
Cuplu de strângere
Wartość momentu Utahovací moment
Ροπή
󼼏󼷛
Measure
Mål Măsurare
Mierz Změřit Μέτρηση
󼮐󼖄
