SOLO AIR SPRING SERVICE
OPTIONAL TRAVEL CHANGE ADJUSTMENT
To change the travel in your suspension fork, replace the entire solo air spring assembly according to the directions below. For part
number information, please refer to the Spare Parts Catalog available on our website at sram.com/service. For ordering information,
please contact your local SRAM distributor or dealer.
Desired Travel Required Solo Air Spring Assembly Length for 26" Required Solo Air Spring Assembly Length for 27.5" and 29"
80 147.2 182.2
90 157.2 192.2
100 167.2 202.2
110 177.2 212.2
120 187.2 222.2
SOLO AIR SPRING REMOVAL
1
Use a small hex wrench to depress the Schrader valve and release
all of the air pressure from the air chamber.
CAUTION- EYE HAZARD
Verify all pressure is removed from the fork before proceeding.
Failure to do so can result in injury and/or damage to the fork.
2
Use a 24 mm socket wrench to remove the air spring top cap.
Once removed, clean the upper tube threads with a rag.
3
Use a pick to remove the top cap o-ring. Apply a small amount of
grease to a new top cap o-ring and install it. Apply a small amount
of grease to the top cap threads.
Do not scratch the top cap. Scratches can cause leaks.
24 mm
10
SOLO AIR SPRING SERVICE
