LOWER LEG INSTALLATION
1
Spray isopropyl alcohol on the upper tubes and clean them with a
rag.
2
Apply a liberal amount of Buzzy's® Slick Honey grease to the inner
surfaces of the dust wiper seals.
Dust wipers may already be pregreased from the factory. If that is
the case, do not apply more grease.
3
Slide the lower leg assembly onto the upper tube assembly just
enough to engage the upper bushing with the upper tubes.
Make sure both dust wiper seals slide onto the tubes without
folding the outer lip of either seal.
4
Position the fork at a slight angle with the shaft bolt holes oriented
upward, then inject 5 mL of RockShox 15wt suspension fluid into
each lower leg through the shaft bolt hole.
21
LOWER LEG INSTALLATION
