SRAM RockShox Reba Series

DAMPER SERVICE
COMPRESSION DAMPER REMOVAL
1
RLT: Use a 1.5 mm hex wrench to remove the gate adjuster set
screw. Remove the gate adjuster, compression adjuster knob, and
the o-ring seal.
RL: Use a 2.5 mm hex wrench to remove the compression adjuster
knob retention screw. Remove the compression adjuster knob.
Remote Only: Use a 2 mm hex wrench to loosen the cable pinch
bolt and remove the cable.
Use a 2 mm hex wrench to loosen the cable stop collar clamping
bolt. Remove the cable stop collar.
You do not need to remove the remote cable spool.
2.5 mm RL
1.5 mm RLT
2 mm RLT
2 mm RL
2 mm
15
DAMPER SERVICE
