2
Use a 24 mm socket to loosen the compression damper top cap.
Remove the compression damper by pulling up and gently rocking
side to side. Clean the upper tube threads with a rag.
3
Use a pick or your fingers to remove the compression damper top
cap o-ring. Apply grease to the new o-ring and install it.
RLT Only: Install a new o-ring on the cam.
Do not scratch the top cap. Scratches can cause leaks.
4
Use a pick or your fingers to remove the compression damper
piston o-ring. Apply suspension fluid to the new o-ring and install
it.
Do not scratch the piston. Scratches may cause air to leak.
5
Remove the fork from the bicycle stand and pour the suspension
fluid into an oil pan.
24 mm
RLT
RL
16
COMPRESSION DAMPER REMOVAL
