1B3-130 OM600 ENGINE MECHANICAL
10. Measure distance ‘z’ (cylinder head cover parting surface
- valve stem).
5. Clean the vales, valve seats and valve guides.
6. Coat the valve stem with oil and insert it into valve guide.
7. Insert the valves (1) into the valve guides according to
marking.
8. Measure amount by which the valve arrears ‘a’.
Arrears ‘a’ 0.1 - 0.7 mm
Notice
If out of standard, replace the valve seat ring.
9. Measure camshaft cam basic diameter (w).
Diameter ‘w’
38 ± 0.2 mm
or 37.6 ± 0.2 mm
