1B3-82 OM600 ENGINE MECHANICAL
CRANKSHAFT BALL BEARING
1 Spacer
2 Cover......................................... Replace
Notice
Manual transmission only.
Tools Required
000 589 33 33 00 Counter Support
000 589 25 33 00 Internal Extractor
Removal & Installation Procedure
1. Remove the manual transmission.
2. Using a puller, pull out the locking ring and ball bearing
together.
Counter Support 000 589 33 33 00
Internal Extractor 000 589 25 33 00
3. Apply Loctite 241 on the new ball bearing and then insert
the ball bearing to be stopped at the spacer ring by using a
proper mandrel.
3 Ball Bearing
4 Bolt .......................................45Nm + 90°
