1B3-178 OM600 ENGINE MECHANICAL
Height ‘A’
(cylinder head surface - cylinder head cover surface)
Minimum height after machining
Permissible unevenness of parting surface
Permissible variation of parallelism (longitud. Direction)
Peak-to-valley height
Valve arrears ‘a’
Prechamber protrusion
Service Data
In longitudinal direction
In transverse direction
Intake valve
Exhaust valve
142.9 - 143.1mm
142.5mm
0.08mm
0.0mm
Max. 0.1mm
0.0017mm
0.1 - 0.7mm
0.1 - 0.7mm
7.6 - 8.1mm
FACING CYLINDER HEAD MATING SURFACE
Preceding Work : Removal of prechamber
Cylinder head pressure leakage test
1 Valve
2 Cylinder Head
3 Prechamber
A Height of Cylinder Head
B Longitudinal Direction
C Transverse Direction
a Valve Arrears
b Prechamber Protrusion
