OM600 ENGINE MECHANICAL 1B3-179
Measurement Procedure
1. Measure height ‘A’ .
Limit 142.5 mm
Notice
If the height is less than 142.5mm, replace the cylinder head.
2. Insert the valve (1) and measure valve arrears ‘a’.
Valve Arrears ‘a’ 0.1 - 0.7 mm
Notice
If out of standard, machine the valve seat.
3. Install the prechamber and measure protrusion ‘C’.
Protrusion ‘C’ 7.6 - 8.1mm
4. Assemble the engine and check the valve timing.
