OM600 ENGINE MECHANICAL 1B3-133
Service Data
Item
Valve Arrears ‘a’
Valve Seat Width ‘b’
Valve Seat Angle ‘α’
Valve Seat Free Angle ‘β’
Permissible Radial Runout
Valve Length ‘I’
Intake
0.1 - 0.7 mm
1.2 - 1.7 mm
45°
65°
0.03 mm
106.20 - 106.60 mm
105.30 - 105.70 mm
Exhaust
0.1 - 0.7 mm
1.5 - 2.0 mm
45°
65°
0.03 mm
106.20 - 106.60 mm
105.30 - 105.70 mm
Standard
Repair
w = 38.0 ± 0.2 mm
Matching Valves
Camshaft cam basic dia.
Size (x)
Size (x)
Size (x)
19.5 - 20.3mm
20.4 - 21.4mm
21.4 - 21.97mm
w = 37.6 ± 0.2 mm
Camshaft cam basic dia.
19.5 - 20.1mm
20.2 - 21.2mm
21.2 - 21.97mm
Valve to be used
Use machined valve,
if needed
use pair valve
1 = 105.5 ± 0.2mm
Reuse valve
Use standard size
valve
I = 106.4 ± 0.2mm
Commercial Tools
Hunger
D-8000 München 70
Type Ventilknecht K2000
Order No. 221 00 100
Hunger
D-8000 München 70
Type VDS 1A
Order No. 236 03 308
Hunger
D-8000 München 70
Order No. 217 93 601
Cylinder Head Clamping Devie
Valve Seat Turning Tool
Test Sat for Valves
