1B3-150 OM600 ENGINE MECHANICAL
In this position, the marking on camshaft / camshaft bearing
cap (arrow) must also be aligned. If the markings are not
aligned, the timing chain must be re-set and the injection
pump timing has to be set.
14. Position the no.1 cylinder at TDC.
11. Place the fitting tool (8) onto the chain link and rivet the
chain pins one by one.
12. Check the riveting of chain pins and re-rivet if necessary.
13. Remove the wire.
Tightening Torque 35 - 40 Nm
