OM600 ENGINE MECHANICAL 1B3-39
Length(L) When New
80mm
102mm
115mm
Thread Dia.
M10
M10
M10
Max. Length(L)
82mm
104mm
117mm
The twelve-sided socket head bolts are tightened with each
stages of torque and torque angle.
It is not necessary to retighten the cylinder head bolts at
the 1000~1500km inspection or after 1000~1500km of
repairs.
Notice
The cylinder head may only be removed when the engine
has cooled down. The cylinder head is removed together
with the exhaust manifold. As the cylinder head bolts
undergo a permanent tightening. They require to be
replaced if they exceed the maximum lengthes indicated
in the table.
