1B3-66 OM600 ENGINE MECHANICAL
18. Remove the timing case cover (19) bolts and then remove
the timing case cover (14).
Notice
Be careful not to damage the cylinder head gasket or oil
pan gasket.
13. Remove the camshaft.
14. Remove the socket bolts(4) in the chain box.
Socket Wrench 115 589 03 07 00
15. Remove the injection pump.
Notice
See the ‘Removal of fuel injection pump’.
16. Remove the oil pan bolts (8, 9) in the area of the timing
case cover (14).
17. Slightly loosen the remaining oil pan bolts.
To Next Page
