1B3-86 OM600 ENGINE MECHANICAL
24.500 - 24.533
24.600 - 24.633
24.700 - 24.733
24.900 - 24.933
25.000 - 25.033
New
Limit
New
Limit
Radial clearances
Axial clearances
Crankshaft bearing
journal diameter
Crankshaft Standard and Repair Sizes
Standard size 50.950 - 57.965
journal width
24.500 - 24.533
24.600 - 24.633
24.700 - 24.733
24.900 - 24.933
25.000 - 25.033
-
Thrust bearing
journal diameter
47.950 - 47.965
Thrust bearing
47.700 - 47.715
47.450 - 47.650
47.200 - 47.215
46.950 - 46.965
57.500 - 57.715
57.450 - 57.465
57.200 - 57.215
56.950 - 56.965
Repair size 1
Repair size 2
Repair size 3
Repair size 4
Bearing Clearances
Thrust bearing Crankshaft bearing
0.026 - 0.068
Max. 0.080
-
-
0.027 - 0.051
Max. 0.070
0.100 - 0.254
Max. 0.300
Matching Fit Bearing Journal Width to Thrust Bearings
Fit bearing journal width Thrust bearings thickness
2.15
2.20
2.25
2.35
2.40
Notice
l Measure crankshaft axial clearance and adjust with proper thrust Bearing.
l The same thickness of washer must be installed on both sides of the fit bearing.
mm
mm
mm
