OM600 ENGINE MECHANICAL 1B3-91
Notice
If the max. length of bolts(L) exceed 63.8mm, replace them.
19. Coat the new crankshaft with engine oil and place it on the
crankcase.
20. Install the crankshaft bearing caps according to marking
and tighten the bolts.
Tightening Torque 55 Nm + 90°
Notice
Install from No. 1 cap.
22. Rotate the crankshaft with hand and check whether it
rotates smoothly.
23. Measure crankshaft bearing axial clearance.
Clearance 0.100 - 0.245mm
Notice
If the clearance is out of standard, adjust the axial clearance
of crankshaft bearing by replacing the thrust washers.
Dial Gauge 001 589 53 21 00
Dial Gauge Holder 363 589 02 21 00
Notice
The same thickness of thrust washers should be installed
on both sides of the thrust bearing.
To Next Page
