OM600 ENGINE MECHANICAL 1B3-95
3. Remove the flywheel (3), if equipped with manual
transmission.
Installation Notice
Correctly align the position of dowel pin (2).
Tools Required
602 589 00 40 00 Engine Lock
Removal & Installation Procedure
1. Install the engine lock.
Engine Lock 602 589 02 40 00
2. Remove the 12-sided stretch bolts (4).
Installation Notice
Tightening Torque 45 Nm + 90°
Notice
If the length ‘L’ of bolts exceeds 22.5mm, replace the bolts.
To Next Page
