Easy Access Operation When Getting Off
When removing the ignition key (key reminder switch OFF) from the ignition switch with the easy access
switch pressed, STICS sends the easy access data to SPWM unit.
The SPWM unit immediately moves the seat backwards for approx. 50 mm and lowers it as far as it
goes.
If an error is detected from the motors (sliding motor/cushion front motor/cushion rear motor) during
operation after removing the ignition key, the motor with error stops its operation and other motors
continue to complete their operations.
easy access stop signal to SPWM unit.
The SPWM overrides all STICS data signals in one second after receiving the easy access stop
signal.
-
-
-
