7410-32
Conditions for Stop and Prohibition of Easy Access Operation
LED on Easy Access Switch
Easy Access Operation Order
The easy access switch is in "OFF" position.
The STICS sends "Stop" signal to SPWM unit when turning off the easy access switch during the
easy access operation.
If STICS receives the easy access switch signal in sequence of ON, OFF, then OFF within one
second during the easy access operation, STICS overrides the third signal and doesn't send any
date to SPWM unit.
If an error is detected on a sensor, the affected motor doesn't operate until it receives normal sensor
input.
The vehicle speed is over 1 km/h.
When the seat switch is operated.
If the shift lever is any position other than "P" or the parking brake is disengaged
1.
2.
3.
4.
5.
6.
7.
LED "ON": Easy access operation is activated.
LED "OFF": Easy access operation is stopped or prohibited.
1.
2.
Moving the seat backward > Raising the front end seat cushion > Raising the rear end seat cushion
There is a 10 ms of pause time between "Moving the seat backward" and "Raising the front end seat
cushion" operations.
1.
2.
