Panel description
Rear panel
7 TX
This RCA jack’s center pin is closed to the ground (open collector output) while
the transmitter is engaged. It may be used to control external linear amplifier.
The maximum voltage is 24 V, the maximum current is 150 mА.
8 ALC
This RCA jack accepts negative-going external ALC (Automatic Level Control)
voltage from a linear amplifier, to prevent over-excitation by the transceiver.
Acceptable input voltage range is 0 to -10 VDC.
9 ANT
Connect your 50 Ω antenna here, using type-UHF (PL-259) plug.
