DP Master Configuration and Programming
39
Uploading an I/O Configuration to the Scanner
To upload the DP master configuration file .bss:
1. Issue the RecbssXmodem command, then initiate an XModem file
upload from your communication software. Refer to the
documentation supplied with your communication software for
more detailed information.
You can also upload a DP master configuration file .2bf using the
Rec2bfXmodem command.
When you upload a configuration file to the scanner, the
configuration is stored in memory on the scanner. If there are
problems with the addresses you have assigned in COM
PROFIBUS, you may get error messages and corresponding
error codes (in hexadecimal). Use the ‘UpdFlash’ command
to store the configuration into flash memory.
