SST-PFB-SLC User’s Guide
64
• The message type, or frame control, FrmCntrl. The message type
can be one of the following:
• the transmit data length, TxLen, in bytes. The allowed values are 0
to 244.
• the transmit data, TxData.
Sending the Message
To send the message, set the appropriate trigger bit in word O:31 of the output
file for the message block.
FC_SDAl 03h Send Data with Ack Lo Pri (SDAL)
FC_SDAh 05h Send Data with Ack Hi Pri (SDAH)
FC_SDNl 04h Send Data No Ack Lo Pri (SDNL)
FC_SDNh 06h Send Data No Ack Hi Pri (SDNH)
FC_SRDl 0Ch Send and Request Data Lo Pri (SRDL)
FC_SRDh 0Dh Send and Request Data Hi Pri (SRDH)
FC_SmTime1 00h First SM time message
FC_SmTime2 80h Second SM time message
FC_SmSDN 02h SM Send Data No ack
FC_SmSRD 01h SM Send and Request Data
FC_SmSRDSltDel 0Ah SM Send and Request Data Slot Del
FC_SmSRDSltKee
p
0Bh SM Send and Request Data Slot Keep
FC_DdbSRD 07h DDB Send and Request Data
FC_DiagSRD 08h Diagnosis Send and Request Data
FC_ReqFDL 09h Request FDL status
FC_ReqId 0Eh Request ID
FC_ReqLSAPSts 0Fh Request LSAP Status
Message block 0123
Message trigger 8 9 10 11
