Using FDL
65
The scanner sends the message. Wait for the message done bit to be set and
check the error bit in word I:31 of the input file.
If there is an error with the message, both the done bit and the error bit will be
set.
Message Replies
The scanner module always fills in the message reply area in the M1 file.
Some of the data comes from the destination station; some comes from the
scanner.
Status has bit 7 set if the message has good status.
The value in Error is 1 if the scanner could not deliver the message. Look in
RspStatus for more information on the cause. The value in Error is 3 if the
transmit length was greater than 244.
Message block 0123
Message done 8 9 10 11
Message error 12131415
Offset Name 0 1 2 3
0 reserved 1122 1252 1382 1512
1 status 1123 1253 1383 1513
2 error 1124 1254 1384 1514
3 reserved 1125 1255 1385 1515
4 RspStatus 1126 1256 1386 1516
5 reserved 1127 1257 1387 1517
6 reserved 1128 1258 1388 1518
7 RxLen 1129 1259 1389 1519
8-129 RxData 1130-1251 1260-1381 1390-1511 1520-1641
