Quick Start Guide of SR Series ©2021 SSZN All Right Reserved
multiple camera controllers are required to share a single encoder, an Encoder
Pulse Signal Allocator is required to expand the encoder signal to multiple
outputs and then connect the corresponding camera controllers separately.
Different control requirements of the system correspond to different connection modes, select the
corresponding wiring diagram to connect on the basis of “Trigger mode” and “Batch start mode”, please refer
to “Figure 6 2 I/O Terminal Wiring Diagram 1”, “Figure 6 2 I/O Terminal Wiring Diagram 1” and “Figure 6 3
I/O Terminal Wiring Diagram 3”. For the “Trigger mode” Setting in EdgeImaging, please refer to “Software
Manual of SR Series 3D Camera”.
