Quick Start Guide of SR Series ©2021 SSZN All Right Reserved
If there is no special specification
when using drag chain, please
select products above R100.
Figure 5- 3 Schematic diagram of minimum bending radius of cable
Cables with connection points shall
not be used on the drag chain.
When using drag chains,
choose cables without
connection points
Figure 5- 4 Selection Diagram for Cable Drag Application
Figure 5- 5 Fixed Camera and Camera Cable Diagram
The cable must be fixed on the
same bracket as the camera about
70mm from the connector plug to
keep it relatively static with the
camera.
