ST FP-SNS-DATALOG2 - Slide 5: STWIN.box development kit - STEVAL-STWINBX1 Hardware Overview

Battery
LiPo-752535 - 480mAh
STWIN.box development kit - STEVAL-STWINBX1
Hardware Overview
STWIN.box - SensorTile Wireless Industrial Node
The STEVAL-STWINBX1 development kit includes:
• The STEVAL-STWBXCS1 STWIN.box core system (main board);
• A plastic case with M3 bolts;
• A 480 mAh 3.7 V LiPo battery;
• The STEVAL-MKIGIBV4 ST-LINK adapter with programming cable;
• The STEVAL-C34DIL24 adapter board for DIL24 sensors with the
STEVAL-FLTCB01 flexible cable.
STEVAL-STWBXCS1
STWIN.box Core System
Plastic Case
STEVAL-MKIGIBV4 + Cable
STLINK Adapter (V2, V2.1)
STEVAL-FLTCB01
34 pin Flex cable
STEVAL-C34DIL24
