ultrasound_fft_app.py is based on the
same Python SDK and modules
developed for hsdatalog_GUI.py.
Following the same procedure
described in 2.1.2, once launched the
acquisition, you can:
• Click on Connect button to allow the
connection between the board and
the PC
• Enable/disable FFT or microphone
data
• Start/stop logging data on the PC
FP-SNS-DATALOG2 - UltrasoundFFT
55
• Once clicked on Start Log button, data are live plotted and the application will create a
YYYYMMDD_HH_MM_SS (i.e., 20200128_16_33_00) folder containing the data and the JSON configuration
file.
