Item Quantity Ref. Part/value Description Manufacturer Order code
18 1 JP4
CONNECTOR
1x4Pts
SAMTEC TSW-104-07-G-S
19 1 JP5
CONNECTOR
NOT FITTED
SAMTEC TSW-105-07-G-S
20 4
JP6, JP7, JP8,
JP9
CONNECTOR
1Pt
SAMTEC TSW-101-07-G-S
21 1 JP11
CONNECTOR
2x4Pts
SAMTEC TSW-104-07-G-D
22 1 JP12 CONNECTOR SAMTEC CES-107-01-L-D
23 1 JP14
CONNECTOR
1x3Pts & 1x1PT
SAMTEC TSW-1xx-07-G-S
24 1 JP16
CONNECTOR
1x3Pts
SAMTEC TSW-103-07-G-S
25 2 L1, L3
EMI FERRITE
BEAD 600
Ohms
WURTH 742792042
26 3 L2, L6, L8
COMMON
MODE FILTER
WURTH 744232090
27 2 L4, L7
EMI FERRITE
BEAD 300
Ohms
WURTH 742792641
28 1 L5
FERRITE CHIP
BEAD
TAI TECH FCM1608KF-601T03
29 1 L9 SELF MURATA BLM18EG471SN1D
30 1 LCD1 LCD MODULE
SHENZHEN
FRIDA
FRD240C48004-A-RT
31 1 LD1 Green LED EVERLIGHT 19-21SYGC/S530-E1/TR8
32 1 LD2 Yellow LED VISHAY TLMY1000-GS08
33 1 LD3 Orange LED EVERLIGHT 19-217/S2C-AM2N2VY/3T
34 1 LD4 Bicolor LED AVAGO HSMF-A201-A00J1
35 3 LD6, LD7, LD8
Green LED
NOT FITTED
EVERLIGHT 19-21SYGC/S530-E1/TR8
36 5
PEG1, PEG2,
PEG3, PEG4,
PEG5
SELF
ADHESIVE
RUBBER
BUMPER
3M SJ5306
37 1 Q1 SOT23 Transistor
UNISONIC
TECH.
MMBT9013L-G-AE3
38 1 Q2
STR2P3LLH6,
SOT-23
P-Channel 30 V,
0.048 Ohm typ.,
2 A STripFET
H6 power
MOSFET in a
SOT-23
package
ST STR2P3LLH6
UM3033
Bill of materials
