ST STEVAL-ST25R3916B - Bill of Materials; Table 3. STEVAL-VOICE-UI Bill of Materials; Table 4. Main Board Bill of Materials

5 Bill of materials
Table 3. STEVAL-VOICE-UI bill of materials
Item Q.ty Ref. Part/Value Description ManµFacturer Order code
1 1
Table 4. STEV
AL$M25R16B
A
- Main board ST
Not available for separate
sale
2 1
Table 5. STEV
AL$D25R16B
A
-
Reader
expansion
board
ST
Not available for separate
sale
Table 4. Main board bill of materials
Item Quantity Ref. Part/value Description Manufacturer Order code
1 6
C1, C10, C13,
C17, C41, C56
1uF 25V ±10%
X5R 0603
CAPACITOR Any Any
2 1 C2
2.2uF 16V
±10% X7R 1206
CAPACITOR Any Any
3 1 C3
10nF 16V ±10%
X7R 0402
CAPACITOR Any Any
4 30
C4, C5, C6, C7,
C8, C11, C12,
C14, C15, C16,
C19, C22, C23,
C24, C25, C26,
C27, C28, C31,
C35, C36, C38,
C42, C43, C44,
C45, C46, C47,
C50, C51
100nF 16V
±10% X7R 0402
CAPACITOR Any Any
5 6
C9, C37, C48,
C49, C54, C55
10uF 25V ±10%
X7R 0603
CAPACITOR Any Any
6 2 C18, C33
4.7nF 50V ±5%
NPO 0402
CAPACITOR Any Any
7 4
C20, C21, C30,
C32
10pF 50V ±5%
NPO 0402
CAPACITOR Any Any
8 1 C29
20pF 0402 NOT
FITTED
CAPACITOR Any Any
9 1 C34
4.7uF 25V
±10% X7R 0603
CAPACITOR Any Any
10 2 C39, C40
100nF 0402
NOT FITTED
CAPACITOR Any Any
11 2 C52, C53
4.7pF ±0.25pF
50V NPO 0402
CAPACITOR Any Any
12 5
D1, D2, D3, D4,
D5
BAT60JFILM,
SOD323
10 V general
purpose signal
Schottky diode
ST BAT60JFILM
13 1 J1 MICRO USB MOLEX AB 47590-0001
14 1 J2 MINI USB B NELTRON 5075BMR-05-SM
15 1 J4 CONNECTOR SAMTEC SSW-114-02-G-S-RA
16 2 J5, J6 CONNECTOR SAMTEC SSW-105-02-G-S-RA
17 6
JP1, JP2, JP3,
JP10, JP13,
JP15
CONNECTOR
1x2Pts
SAMTEC TSW-102-07-G-S
UM3033
Bill of materials
UM3033 - Rev 1
page 22/34
