ST STM32F0DISCOVERY User Manual

Connecting modules on the prototyping board UM1525
34/41 Doc ID 022910 Rev 2
Arduino ICSP connector STM32F0DISCOVERY
1 MISO PB4 SPI1_MISO
2 VCC 3.3V 3V VDD
3 SCK PB3 SPI1_SCK
4 MOSI PB5 SPI1_MOSI
5 RST NRST Reset discovery
6 GND GND Reference Ground
Connecting with Arduino shields (continued)
