Connectors UM1907
20/49 DocID027942 Rev 3
7.3 Arduino Uno V3 connectors
CN4, CN5, CN6 and CN7 are female connectors compatible with Arduino standard. Most
shields designed for Arduino can fit to the STM32F746G-DISCO discovery board.
The Arduino connectors on STM32F746G-DISCO discovery board support the Arduino Uno
V3.
Caution: The IOs of STM32 microcontroller are 3.3 V compatible instead of 5 V for Arduino Uno.
6 DCMI_D2 21 Camera_CLK (OSC_24M)
7 DCMI_D3 22 NC
8DCMI_D423 GND
9 DCMI_D5 24 NC
10 DCMI_D6 25 DCMI_PWR_EN
11 DCMI_D7 26 DCMI_NRST
12 NC 27 DCMI_SDA
13 NC 28 DCMI_SCL
14 GND 29 GND
15 DCMI_PIXCK 30 3V3
Table 2. Camera module connector P1 (continued)
Pin number Description Pin number Description
