DocID027942 Rev 3 39/49

UM1907 STM32F746G-DISCO IO assignment

Appendix A STM32F746G-DISCO IO assignment

Table 10. STM32F746G-DISCO IO assignment

Pin No. Pin Name Signal or Label Comment

A1 PE4 LTDC_B0 -

A2 PE3 OTG_HS_OverCurrent -

A3 PE2 QUADSPI_BK1_IO2 -

A4 PG14 ETH_TXD1 -

A5 PE1 FMC_NBL1 -

A6 PE0 FMC_NBL0 -

A7 PB8 ARDUINO SCL/D15 -

A8 PB5 USB_OTG_HS_ULPI_D7 -

A9 PB4 ARDUINO PWM/D3 -

A10 PB3 SYS_JTDO-SWO -

A11 PD7 SPDIF_RX0 -

A12 PC12 SDMMC_CK -

A13 PA15 ARDUINO PWM/D9 -

A14 PA14 SYS_JTCK-SWCLK -

A15 PA13 SYS_JTMS-SWDIO -

B1 PE5 DCMI_D6 -

B2 PE6 DCMI_D7 -

B3 PG13 ETH_TXD0 -

B4 PB9 ARDUINO SDA/D14 -

B5 PB7 VCP_RX -

B6 PB6 QUADSPI_BK1_NCS -

B7 PG15 FMC_SDNCAS -

B8 PG11 ETH_TX_EN -

B9 PJ13 LTDC_B1 -

B10 PJ12 OTG_FS_VBUS

(1)

B11 PD6 Audio_INT -

B12 PD0 FMC_D2_DA2 -

B13 PC11 SDMMC_D3 -

B14 PC10 SDMMC_D2 -

B15 PA12 USB_OTG_FS_DP -

C1 VBAT - Connected to VDD

C2 PI8 NC1 -
